Output power RMS ≤ 1% THD+N – @ 4 Ohms 4 x 100 Watts – @ 2 Ohms 4 x 100 Watts – @ 1 Ohm – – bridged @ 4 Ohms 2 x 200 Watts – bridged @ 2 Ohms – Max. output power per channel* Up to 135 Watts RMS @ 4 / 2 Ohms Amplifier technology Class D Inputs 4 x RCA / Cinch 4 x Highlevel speaker input 1 x Remote In Input sensitivity RCA / Cinch 0.5 – 6 Volts Highlevel 1.3 – 13 Volts Input impedance RCA / Cinch 20 kOhms Input impedance highlevel 9 – 33 Ohms Outputs 4 x Speaker output Output voltage RCA / Cinch – Signal converter for digital input – Frequency response 10 Hz – 30, 000 Hz Bass boost – Highpass 15 Hz – 4, 000 Hz adjustable Lowpass 40 Hz – 4, 000 Hz adjustable Bandpass 15 Hz – 4, 000 Hz adjustable Subsonic – Phase – Slope high- / lowpass 12 dB/Oct. Slope subsonic / lowpass – Signal-to-noise ratio digital input – Signal-to-noise ratio analog input 98 dB (A-weighted) Distortion (THD) 0.05 % Damping factor 100 Operating voltage 18 – 36 Volts (max. 5 sec. down to 12 Volts) Idle current 550 mA Fuse 2 x 15 A Maxi-fuse (APX) Power rating DC 24 V ⎓ 25 A max. Additional features Active, adjustable crossover, input mode switch, Start-Stop capability, highlevel input with automatic turn on function and Advanced Diagnostics Error Protection (ADEP) Dimensions (H x W x D) 50 x 230 x 154 mm / 2.00 x 9.06 x 6.06”
