Technical data Output power RMS / max. – @ 4 OhmsChannels A – F: 6 x 65 Watts – @ 2 Ohms- – @ 1 Ohm- – bridged @ 4 Ohms- – bridged @ 2 Ohms- – Subwoofer output @ 4 OhmsKanal G – H: 2 x 90 Watts – Subwoofer output @ 2 OhmsKanal G – H: 2 x 160 Watts Amplifier technologyClass GD Inputs6 x Highlevel speaker input 1 x Optical SPDIF (12 – 96 kHz) 1 x MEC 1 x Remote In Input sensitivity2.8 – 11 Volts Input impedance RCA / Cinch- Input impedance highlevel9 – 33 Ohms with ADEP.3 Outputs8 x Speaker output 1 x RCA / Cinch 1 x Remote Out Output voltage RCA / Cinch3 Volts RMS Frequency response10 Hz – 22, 000 Hz DSP resolution64 Bit DSP power295 MHz (1.2 billion MAC operations/second) Sampling rate48 kHz DSP typeAudio signal processor Signal convertersA/D: BurrBrown D/A: BurrBrown Signal-to-noise ratio digital input106 dB (A-weighted) Signal-to-noise ratio analog input104 dB (A-weighted) Distortion (THD) 0.03 % Damping factor 100 Operating voltage10.5 – 17 Volts (max. 5 sec. down to 6 Volts) Power ratingDC 12 V ⎓ 40 A max. Idle current380 mA Max. remote output current500 mA Fuse2 x 25 A LP-Mini-fuse (APS) Additional featuresClass GD technology with dynamically controlled power supply, 32 Bit CoProcessor, ADEP.3 circuit, Start-Stop capability, Smart Control Port, USB, MEC slot, Auto Remote switch, galvanically isolated Line Out Dimensions (H x W x D)46 x 130 x 153 mm / 1.81 x 5.12 x 6.02".
