MATCH UP 1FX

Match kompaktin kokoinen ja tehokas D-luokan monovahvistin

299.00  sis alv24%

Pyydä tarjous! Pyyntihinta ei ole välttämättä myyntihinta ;)

Varastossa

Kuvaus

Match erittäin laadukas monovahvistin, joka soveltuu yhteen erinomaisesti muiden UP -sarjan vahvistimien kanssa.

– Loistava äänenlaatu ja paljon tehoa pienessä paketissa ( jopa 1000W RMS @1ohm )

– 32V RMS kaiutintasoiset sisääntulot varustettuna autostart ominaisuudella

– Start-Stop yhteensopiva uusimpien autojenkin kanssa.

– DirectDSP-toiminto: tulosignaali ohittaa integroidun, aktiivisen jakosuotimen ja jatkuu siitä suodattamattomana vahvistimen ulostuloon

– CLIP-led, joka varoittaa signaalin särölle menosta ja helpottaa näin gain -säätöä

Tuki langalliselle tasonsäätimelle ( saatavana erikseen )

– Sopii loistavasti muiden Match UP -vahvistimien perään mono RCA -sisääntulosta johtuen

Lisätiedot

Paino 1.7 kg (kilogramma)
Tekniset tiedot

Technical data: Power RMS – @ 4 Ohms 1 x 350 Watts – @ 2 Ohms 1 x 600 Watts – @ 1 Ohm 1 x 900 Watts* – bridged @ 4 Ohms – – bridged @ 2 Ohms – Max. output power Up to 1000 Watts RMS @ 1 Ohm Amplifier technology Class D Inputs 1 x RCA / Cinch 2 x Highlevel speaker input 1 x Remote In 1 x Remote control input Input sensitivity RCA / Cinch 0.5 – 3 Volts or 1 – 6 Volts Highlevel 2.5 – 16 Volts or 5 – 32 Volts Input impedance RCA / Cinch 8.6 kOhms Input impedance highlevel 9 – 33 Ohms Outputs 1 x Speaker output Output voltage RCA / Cinch – Signal converter for digital input – Frequency response 10 Hz – 25, 000 Hz Bass boost – Highpass – Lowpass 50 Hz – 250 Hz adjustable (can be turned off) Bandpass – Subsonic 15 Hz (can be turned off) Phase – Slope high- / lowpass 12 dB Slope subsonic / lowpass 12 dB Signal-to-noise ratio digital input – Signal-to-noise ratio analog input 108 dB (A-weighted) Distortion (THD) 0.002 % Damping factor 160 Operating voltage 10.5 – 18 Volts (max. 5 sec. down to 6 Volts) Idle current 1050 mA Fuse 2 x 30 A LP-Mini-fuse (APS) Power rating DC 12 V ⎓ 80 A max. Ambient operating temperature range -40 °C to +70 °C Additional features Active, adjustable crossover, Start-Stop capability, highlevel input with automatic turn on function and Advanced Diagnostics Error Protection (ADEP), bass volume cable remote control Dimensions (H x W x D) 46 x 130 x 153 mm / 1.81 x 5.12 x 6.02" Scope of delivery: 1 x Amplifier MATCH UP 1FX 1 x Mounting plates and material 1 x Instruction manual

Technical data:
Power RMS
- @ 4 Ohms 1 x 350 Watts
- @ 2 Ohms 1 x 600 Watts
- @ 1 Ohm 1 x 900 Watts*
- bridged @ 4 Ohms -
- bridged @ 2 Ohms -
Max. output power Up to 1000 Watts RMS @ 1 Ohm
Amplifier technology Class D
Inputs 1 x RCA / Cinch
2 x Highlevel speaker input
1 x Remote In
1 x Remote control input
Input sensitivity RCA / Cinch 0.5 - 3 Volts or 1 - 6 Volts
Highlevel 2.5 - 16 Volts or 5 - 32 Volts
Input impedance RCA / Cinch 8.6 kOhms
Input impedance highlevel 9 - 33 Ohms
Outputs 1 x Speaker output
Output voltage RCA / Cinch -
Signal converter for digital input -
Frequency response 10 Hz - 25,000 Hz
Bass boost -
Highpass -
Lowpass 50 Hz - 250 Hz adjustable (can be turned off)
Bandpass -
Subsonic 15 Hz (can be turned off)
Phase -
Slope high- / lowpass 12 dB
Slope subsonic / lowpass 12 dB
Signal-to-noise ratio digital input -
Signal-to-noise ratio analog input 108 dB (A-weighted)
Distortion (THD) 0.002 %
Damping factor 160
Operating voltage 10.5 - 18 Volts (max. 5 sec. down to 6 Volts)
Idle current 1050 mA
Fuse 2 x 30 A LP-Mini-fuse (APS)
Power rating DC 12 V ⎓ 80 A max.
Ambient operating temperature range -40 °C to +70 °C
Additional features Active, adjustable crossover, Start-Stop capability, highlevel input with automatic turn on function and Advanced Diagnostics Error Protection (ADEP), bass volume cable remote control
Dimensions (H x W x D) 46 x 130 x 153 mm /
1.81 x 5.12 x 6.02″

Scope of delivery:
1 x Amplifier MATCH UP 1FX
1 x Mounting plates and material
1 x Instruction manual
