Power RMS ≤ 1% THD+N

– @ 4 OhmsChannel A – F: 6 x 120 Watts

– @ 2 OhmsChannel C – F: 4 x 230 Watts

Max. output power per channel*
Channel A – F: up to 145 Watts RMS @ 4 Ohms
Channel C – F: up to 285 Watts RMS @ 2 Ohms

Amplifier technologyUltra HD Class D

Inputs:

6 x RCA / Cinch
6 x Highlevel speaker input
1 x Optical SPDIF (12 – 96 kHz)
1 x Coax SPDIF (12 – 192 kHz)
1 x Remote In

Input sensitivityRCA / Cinch 1 – 4 Volts or 4 – 8 Volts
Highlevel 4 – 16 Volts or 8 – 32 Volts

Input impedance RCA / Cinch13 kOhms

Input impedance highlevel9 – 33 Ohms with ADEP.3

Outputs:

6 x Speaker output
4 x RCA / Cinch
1 x Optical SPDIF (96 kHz)
2 x Remote Out

Output voltage RCA / Cinch3 Volts

Frequency response10 Hz – 44,000 Hz

DSP resolution64 Bit

DSP power2 x 295 MHz (2.4 billion MAC operations/second)

Sampling rate96 kHz

DSP type2 x Audio signal processor

Signal convertersA/D: BurrBrown

D/A: BurrBrown

Signal-to-noise ratio digital input108 dB (A-weighted)

Signal-to-noise ration analog input102 dB (A-weighted)

Distortion (THD) 0,004 %

Damping factor 100

Operating voltage10.5 – 32 Volts (max. 5 sec.down to 6 Volts)

Power ratingDC 12 / 24 V ⎓ 65 A max.

Idle current1350 mA

Max. remote output current500 mA

Fuse3 x 20 A LP-Mini-fuse (APS)

Additional features32 Bit CoProcessor, HEC slot, ADEP circuit, Auto Remote switch, Smart Control Port

Dimensions (H x W x D)50 x 260 x 190 mm /
1.97 x 10.24 x 7.48“

Scope of delivery
1 x Amplifier HELIX P SIX DSP ULTIMATE
1 x Control Input-to-SCP adaptor
1 x USB cable
2 x Allen key
1 x Mounting material
1 x Instruction manual.
