– @ 4 Ohms6 x 100 Watts
– @ 2 Ohms6 x 100 Watts
– @ 1 Ohm-
– bridged @ 4 Ohms3 x 200 Watts
– bridged @ 2 Ohms-
Max. output power per channel*Up to 130 Watts RMS @ 4 / 2 Ohms
Amplifier technologyClass D
Inputs6 x RCA / Cinch
6 x Highlevel speaker input
1 x Optical SPDIF (12 – 96 kHz)
1 x Remote In
Input sensitivityRCA / Cinch 1 – 4 Volts
Highlevel 5 – 20 Volts
Input impedance RCA / Cinch22 kOhms
Input impedance highlevel9 – 33 Ohms or 20 kOhms
Outputs6 x Speaker output
4 x RCA / Cinch
2 x Remote Out
Output voltage RCA / Cinch6 Volts
Frequency response20 Hz – 22,000 Hz
DSP resolution64 Bit
DSP power295 MHz (1.2 billion MAC operations/second)
Sampling rate48 kHz
DSP typeAudio signal processor
Signal-to-noise ratio digital input105 / 108 dB Speaker / Line Output (A-weighted)
Signal-to-noise ration analog input102 / 105 dB Speaker / Line Output (A-weighted)
Distortion (THD) 0.03 / 0.005 % Speaker / Line Output
Damping factor100
Operating voltage10.5 – 16 Volts (max. 5 sec.down to 6 Volts)
Idle current1950 mA
Max. remote output current500 mA
Fuse2 x 35 A Maxi-fuse (APX)
Power ratingDC 12 V ⎓ 80 A max.
Additional featuresADEP.3 circuit, Auto Remote switch, 32 Bit CoProcessor, Control Input
Dimensions (H x W x D)50 x 320 x 154 mm /
2.00 x 12.60 x 6.06″.
