RMS Power @ 4 Ω (@ 100 Hz) * 500 W (1% THD+N)
RMS Power @ 2 Ω (@ 100 Hz) * 900 W (1% THD+N)
RMS Power @ 1 Ω (@ 100 Hz) * 1350 W (1% THD+N)
Max. Power @ 1 Ω (@ 100 Hz) 1500 W (10% THD+N)
Low pass filter 80 Hz – 22 kHz (12 dB/oct)
High pass filter 15 Hz – 80 Hz (12 dB/oct
Frequency response 10 Hz – 22 kHz (± 3 dB)
Total harmonic distortion (THD+N) 0.05%
Damping factor 100
Signal-to-noise ratio 90 dB
Input sensitivity 170 mV – 10 V
Input Impedance 20 kΩ
Rec. speaker wire ≥ 4 mm² / 11 AWG
Rec. power wire ≥ 35 mm² / 2 AWG
Max. current 140 A
Dimensions w x h x l (heatsink / overall) 230 x 67 x 118/142 mm
Dimensions w x h x l (heatsink / overall) 9,06“ x 2,64“ x 4,65“/5,60“.
